Wellav CMP201D - CE2-SDI-00 Status; CE2-SDI-00 Basic Settings

CMP201D User Guide
60
Setting Range:
Video Encode
Settings
Range
Video Encode
Settings
Range
Audio Encode Settings
Range
Audio Encode Settings
Range
Input Source Type
Audio Source
Audio Type
SDI
CVBS
SDI1(2/3/4)
Analog
AC3
AC3_Passthrough
MPEG1_Layer2
MPEG2_AAC
MPEG4_AAC
Audio Bit Rate(Kbps)
Audio AAC Format
128~384 (AC3)
64~384(MPEG1_Lay
er2/MPEG2_AAC/
AC3_Passthrough)
16~384(MPEG4_AA
C)
ADTS
LATM
Volume
-20~20
Audio PID
32~8190
Input Source Type
CVBS, SDI
GOP Size
18~48
Video Type
H264 , MPEG2
PCR2 PID
32~8190
Video Bit Rate (Kbp
s)
2000~18000
PMT PID
32~8190
Video Mode
CBR
Program Name
Length is 1~31
CC
Disable, Enable
Provider Name
Length is 0~31
Video PID
32~8190
Video Aspect Ratio
Auto
16x9
4x3
GOP Structure
IPPB, IPPP, IBP
P Frame
IBBP
P Frame: 5~15
IPPP
P Frame: 18~47
IBP
P Frame: 8~23
