3 ‒ Technical Data | P1PY201 ‒ Laser Distance Sensor ToF 10
3 Technical Data
3.1 General Data
Technical Data
Optical Data
Working Range 0 ... 10000 mm
Setting Range 50 ... 10000 mm
Reproducibility maximum 3 mm*
Linearity Deviation 10 mm*
Switching Hysteresis < 15 mm
Light Source Laser (red)
Wavelength 660 nm
Service Life (T = +25 °C) 100000 h
Laser Class (EN 60825-1) 1
Beam Divergence < 2 mrad
Max. Ambient Light 100000 Lux
Light Spot Diameter
See section Light Spot Diameter [}11]
Electrical Data
Supply Voltage 18 ... 30 V DC
Current Consumption (Ub = 24 V) < 60 mA
Switching Frequency 50 Hz*
Switching Frequency (max.) 250 Hz*
Response Time 15 ms *
Response Time (min.) 4.7 ms *
Temperature Drift < 0,4 mm/K
Temperature Range -40 ... 50 °C**
Number of Switching Outputs 2
Switching Output Voltage Drop < 2.5 V
Switching Output/Switching Current 100 mA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Interface IO-Link V1.1.3
Baud Rate COM3
Protection Class III
Mechanical Data
Setting Method (OLED)/Bluetooth menu
Housing Material Plastic, ABS
Optic Cover Plastic, PMMA
Degree of Protection IP67
Connection M12 × 1; 4/5-pin
Contains FCC ID: 2A3OLDC1392 x
Output Functions
Output PNP
NO
Technical Safety Data
MTTFd (EN ISO 13849-1) 369.13 a
* Depends on mode, see section Mode-Dependent Data [}11]
