8 ‒ Function Description | P1PY201 ‒ Laser Distance Sensor ToF 27
8.3 Input/Output Functions (E/A)
8.3.1 Pin Function
The pin function is used to define the function of pins I/O1, I/O2, and I3, as these can be used for differ-
ent functions.
Pin Possible settings Default
E/A1 Switching output
Switching point SSC1 is assigned to the switching output.
Error output
The error output switches if one of the assigned errors occurs;
see table Status messages [}32].
Warning output
The warning output switches if one of the assigned warnings
occurs; see table Status messages [}32].
Laser-off input
See E3 for an explanation
Teach-in input
See E3 for an explanation
Speed measurement reset input
See E3 for an explanation
Deactivated
The pin is deactivated.
Switching output
E/A2 Switching output
Switching point SSC2 is assigned to the switching output.
Antivalent switching output
The switching output switches antivalently to switching output
A1.
Error output
The error output switches if one of the assigned errors occurs;
see table Status messages [}32].
Warning output
The warning output switches if one of the assigned warnings
occurs; see table Status messages [}32].
Laser-off input
See E3 for an explanation
Teach-in input
See E3 for an explanation
Speed measurement reset input
See E3 for an explanation
Deactivated
The pin is deactivated.
Switching output
E3 Laser-off input
The sensor’s emitted light is deactivated as long as the input
is activated. The sensor then does not send a measured value
and sets the status to “No signal”.
Teach-in input
Teach-in
Laser off
Input
