8 ‒ Function Description | P1PY201 ‒ Laser Distance Sensor ToF 34
In addition, the individual outputs and status messages can be simulated separately from the measured
value.
Function Possible settings Default
Simulation mode On
Off
Off
Test
measured value
Current measured value
min...max. measuring range
Current measured
value
SSC1 Test According to the measured value
On
Off
According to mea-
sured value
SSC2 Test According to the measured value
On
Off
According to mea-
sured value
Status messages test Tests the individual status messages
according to the measured value
On
Off
According to
measured value
INFORMATION
Output A1 is used for IO-Link communication in this function and cannot be simulated.
Simulation mode ends automatically as soon as the power supply is interrupted.
