Westen pulsar D User Manual

17
926.323.1 - GB
INSTRUCTIONS FOR FITTERS
Consumption 15°C-1013 mbar 24 -1.24 24 F -1.24 F
G20  G31 G20  G31
Rated power 2,78 m
3
/h 2,04 kg/h 2,73 m
3
/h 2,00 kg/h
Reduced power 1,12 m
3
/h 0,82 kg/h 1,12 m
3
/h 0,82 kg/h
p.c.i. 34,02 MJ/m
3
46,34 MJ/kg 34,02 MJ/m
3
46,34 MJ/kg
Table of burner injectors
24 -1.24 24 F -1.24 F
gas type G20 G31 G20 G31
diameter of nozzles (mm) 1,18 0,77 1,35 0,85
Burner pressure (mbar*) 2.5 5,4 2,3 5,4
REDUCED HEAT OUTPUT
Burner pressure (mbar*) 13,1 29,3 11,3 28,5
RATED HEAT OUTPUT
N° nozzles 13 11
Consumption 15°C-1013 mbar 1.14 1.14 F
G20  G31 G20  G31
Rated power 1,63 m
3
/h 1,20 kg/h 1,60 m
3
/h 1,17 kg/h
Reduced power 0,75 m
3
/h 0,55 kg/h 0,75 m
3
/h 0,55 kg/h
p.c.i. 34,02 MJ/m
3
46,34 MJ/kg 34,02 MJ/m
3
46,34 MJ/kg
Table 2
1.14 1.14 F
gas type G20 G31 G20 G31
diameter of nozzles (mm) 1,18 0,77 1,18 0,77
Burner pressure (mbar*) 1.8 4,0 1,8 4,0
REDUCED HEAT OUTPUT
Burner pressure (mbar*) 8,0 17,7 7,1 15,6
RATED HEAT OUTPUT
N° nozzles 10 11
* 1 mbar = 10,197 mm H
2
O
Table 1
