WHILL F - Page 33

32
WHILL Model F User Manual
3
Installation pattern 2
The following explanation is for when the product is used at the following specifications.
Position of controller Space between arm rests
Right side
Wide
1.
Remove the cover from the arm rest with controller.
Press the location shown by the arrow in the figure
to remove the two tabs, and separate the left and
right covers.
Remove the cover.
2.
Disconnect the cable attached to the inside of the
cover.
