WHILL Model F User Manual
3
3. Assembly and adjustment
3.
Remove the controller from the arm rest with
controller.
Turn the screw to remove together with the fixture.
Remove the controller by sliding it in the direction
of the arrow.
Do not pull it forcefully. There is a risk of breaking
the cable that is connected to it.
Controller
4.
Remove the cover from the arm rest with hand rest.
Press the location shown by the arrow in the figure
to remove the two tabs, and separate the left and
right covers.
Remove the cover.
5.
Remove the hand rest of the arm rest with hand rest.
Turn the screw to remove together with the fixture.
Remove the hand rest by sliding it in the direction of
the arrow.
Hand rest
