Troubleshooting & Diagnostic:
Fridge temperature too cold in meat-pan drawer
Be sure that meat-pan slider is closed (‘vegetable’
position). Clean damper and air duct from ice, check
if the damper is always in closed position.
If damper will not open, cold air from
freezer could pass through this
passage. Change the damper.
YesNo
- On very old appliances (before w41 2002), in case of iced meat-pan
slider: change of the slider as described in the Service Bulletin 4812
711 40145.
- On appliances produced before w23 2007: close partially the inlet air
duct in the freezer compartment. After this date, an air duct reduction
(air passage 40% reduced) was used (as shown in pictures below)
To Next Page
