Whirlpool Cassinetta - Ice Formation on the Freezer Bottom

65
Old appliances (until range 2007)
Check the correct position of the
membrane, as shown in the picture below.
Check the drain tube connection
and fix / clean it if necessary.
New appliances
Troubleshooting & Diagnostic:
Ice formation on the freezer bottom.
For appliances until range 2007:
The membrane on the outcoming tube to the drip tray
could be loosing (falling down). In this case warm air with
humidity enter into the freezer compartment and cause
the ice formation.
For all appliances:
The outcoming tube to the drip
tray could be blocked or
disconnected from the
evaporator tray.
