20
Current electronic control architecture, instruction for connection:
BIRUNI electronic boards connections:
The right connections for all
different versions of Biruni
electronic board are:
NO I&W: Main power
NO IDI: Main power + Heater
niche + Heater door
IDI: Main power + Ice paddle +
Water paddle + Light + Motor
ice door
MAIN BOARD
USER INTERFACE
Only one supplier for the
electronic Main Board
