Whirlpool Cassinetta - Fridge Compartment Temperature too Warm and Freezer Compartment Completely Frozen (- 28°C)

63
Reason:
The sensor wires are
inverted at the connector side
(freezer wire in the refrigerator
connector position and opposite).
Change the connector position.
Troubleshooting & Diagnostic:
Fridge compartment temperature too warm and
Freezer compartment completely frozen (- 28°C).
4 3
2 1
Freezer Sensor :
Pin 2 = blue wire
Pin 4 = brown wire
Fridge Sensor :
Pin 1 = blue wire
Pin 3 = brown wire
ITW BOARD
FLEXTRONICS BOARD
