3.5 Labelling, safety marks
■
Head mounting version, model T16.H
■
Rail mounting version, model T16.R
Before mounting and commissioning the instrument, ensure you
read the operating instructions!

Model

Firmware

Date of manufacture (year-month)

Serial number

Sensor information (model, connection
method, power supply, measuring range)

Approval-related data

TAG no.

Pin assignment
 













