5. Commissioning, operation
14147933.02 10/2018 EN/DE
WIKA operating instructions model T16
19
5.4 Configuration
Configurable are
■
Sensor type
■
Measuring range
■
Unit
■
Signalling
■
Measuring range monitoring
■
Damping
■
Write protection
■
“Several” TAG numbers
■
2-point scaling
The temperature transmitters are delivered with a basic configuration (see data sheet
TE 16.01) or configured according to customer specifications. If the configuration is
changed afterwards, the modifications must be noted on the product label using a water-
resistant fibre-tip pen.
A simulation of the input value is not required to configure the T16. A sensor
simulation is only required for the functional test.
5.4.1 Configurable monitoring functionality
Measuring range monitoring:
If this function is activated, an error is signalled on the current loop if the measured value is
either below or over the limits of the measuring range.
5.4.2 Configuration via the PC
Configuration is carried out using a USB interface with a PC via the model PU-548
programming unit (see chapter 12 “Accessories”) and the WIKAsoft-TT configuration
software.
The required Windows device driver for the PU-548 is a component of the
current Windows
®
operating system.
Windows
®
is a registered trademark of Microsoft Corporation in the United States and other countries.
