11. Specifications
14147933.02 10/2018 EN/DE
WIKA operating instructions model T16
28
11. Specifications
DANGER!
Danger to life due to loss of explosion protection
The non-observance of the instructions for use in hazardous areas can lead
to the loss of the explosion protection.
▶
Adhere to the following limit values and instructions.
Specifications Model T16
Permissible ambient temperature range {-50} -40 ... +85 {+105} °C
{-58} -40 ... +185 {+221} °F
Climate class per IEC 654-1:1993 Cx (-40 ... +85 °C / -40 ... +185 °F, 5 ... 95 % r. h.)
Maximum permissible humidity
■
Model T16.H
per IEC 60068-2-38:2009
■
Model T16.R
per IEC 60068-2-30:2005
Test max. temperature variation 65 °C (177 °F) /
-10 °C (-18 °F), 93 % ±3 % r. h.
Test max. temperature 55 °C (131 °F), 95 % r. h.
Vibration resistance
per IEC 60068-2-6:2008
Test Fc: 10 ... 2,000 Hz; 10 g,
amplitude 0.75 mm (0.03 in)
Shock resistance
per IEC 68-2-27:2009
Acceleration / Shock width
Model T16.H: 100 g / 6 ms
Model T16.R: 30 g / 11 ms
Salt fog
per IEC 68-2-52:1996, IEC 60068-2-52:1996
Severity level 1
Condensation Model T16.H: Acceptable
Model T16.R: Acceptable in vertical mounting
position
Free fall
in line with IEC 60721-3-2:1997,
DIN EN 60721-3-2:1998
Drop height 1.5 m (4.9 ft)
Electromagnetic compatibility (EMC)
per DIN EN 55011:2010, DIN EN 61326-2-3:2013,
NAMUR NE21:2012, GL 2012 VI Part 7
EN 61326 emission (group 1, class B) and
interference immunity (industrial application)
[HF field, HF cable, ESD, Burst, Surge]
{ } Items in curved brackets are options for an additional price, not for ATEX versions of the head mounting version and not for
T16.R rail mounting version
