23
WILDEN PUMP & ENGINEERING, LLCWIL-10230-E-02
T8 PLASTIC RUBBER/TPE-FITTED
Item Part Description Qty.
T8/PKAPB
P/N
T8/PKSSB
P/N
T8/PKWPB
P/N
T8/PKCPC/0502
P/N
1 Air Valve Assembly
1
1 08-2000-07 08-2000-07 08-2000-07 08-2000-05
2 Air Valve Screen 1 08-2500-07 08-2500-07 08-2500-07 08-2500-07
3 Air Valve End Cap w/Guide (Top) 1 08-2300-23 08-2300-23 08-2300-23 08-2300-23
4 Air Valve End Cap w/o Guide (Bottom) 1 08-2330-23 08-2330-23 08-2330-23 08-2330-23
5 End Cap Cover (Not shown) 2 N/R N/R N/R 08-2420-55
6 End Cap Bolt (Not shown) 2 N/R N/R N/R 08-2450-22
7 Air Valve Snap Ring 2 08-2650-03 08-2650-03 08-2650-03 08-2650-03
8 Air Valve Cap O-Ring 2 08-2390-52 08-2390-52 08-2390-52 08-2390-52
9 Oil Bottle (Optional) 1 08-2850-01 08-2850-01 08-2850-01 N/A
10 Plug (Optional) 1 08-7000-07 08-7000-07 08-7000-07 N/A
11 Capillary Rod (Optional) 1 08-2900-99 08-2900-99 08-2900-99 N/A
12 Air Valve Gasket — Buna-N 1 08-2600-52 08-2600-52 08-2600-52 08-2600-52
13 Air Valve Screw 4 08-6000-03 08-6000-03 08-6000-03 08-6000-05
14 Center Block 1 08-3100-20-225 08-3100-20-225 08-3100-20-225 08-3100-20-225
15 Center Block Glyd™ Ring 7 08-3210-55-225 08-3210-55-225 08-3210-55-225 08-3210-55-225
16 Block Gasket — Buna-N 2 08-3520-52 08-3520-52 08-3520-52 08-3520-52
17 Shaft 1 08-3800-09-07 08-3800-09-07 08-3800-09-07 08-3800-09-07
Shaft, Ultra-Flex™ 1 08-3820-03-07 08-3820-03-07 08-3820-03-07 08-3820-03-07
18 Piston, Outer 2 08-4550-21-500 08-4550-21-500 08-4550-21-500 08-4550-21-500
Piston, Outer, Ultra-Flex™ 2 08-4560-21 08-4560-21 08-4560-21 08-4560-21
29 Piston, Inner 2 08-3700-01 08-3700-03 08-3700-01 08-3700-01
Piston, Inner, Ultra-Flex™ 2 04-3700-08 04-3700-08 04-3700-08 04-3700-08
20 Air Chamber, Counter Sunk 2 08-3650-01 08-3650-03 08-3650-02 08-3650-05
21 Air Chamber Screw - 3/8”-16 x 3-9/16” 3 08-6200-08 08-6200-03 08-6200-08 08-6200-03
22 Air Chamber Cone Nut 3/8”-16 3 08-6550-08 08-6550-03 08-6550-08 08-6550-03
23 Liquid Chamber 2 08-5000-20 08-5000-20 08-5000-20 08-5000-20
24 Discharge Elbow 2 08-5230-20 08-5230-20 08-5230-20 08-5230-20
25 Inlet Elbow 2 08-5220-20 08-5220-20 08-5220-20 08-5220-20
26 Manifold T-Section 2 08-5160-20 08-5160-20 08-5160-20 08-5160-20
27 Ball Guide Bushing 4 08-5350-20-500 08-5350-20-500 08-5350-20-500 08-5350-20-500
28 Valve Seat O-Ring* 4 ****
29 Manifold O-Ring* 4 ****
30 Diaphragm* 2 ****
31 Diaphragm, Backup 2 N/A N/A N/A N/A
32 Valve Ball* 4 ****
33 Valve Seat 4 08-1120-20-500 08-1120-20-500 08-1120-20-500 08-1120-20-500
34 Large Clamp Band, Assy. 2 08-7300-03-500 08-7300-03-500 08-7300-03-500 08-7300-05-500
35 Large Carriage Bolt 3/8”-16 x 2-1/2” 4 08-6070-03-500 08-6070-03-500 08-6070-03-500 08-6070-05-500
36 Large Hex Nut 3/8”-16 4 08-6450-03 08-6450-03 08-6450-03 08-6420-05
37 Medium Clamp Band, Assy. 4 08-7200-03-500 08-7200-03-500 08-7200-03-500 08-7200-05-500
38 Medium Carriage Bolt 5/16”-18 x 2-1/4” 8 04-6070-03 04-6070-03 04-6070-03 04-6070-05
39 Medium Hex Nut 5/16”-18 8 08-6400-03 08-6400-03 08-6400-03 08-6400-05
40 Small Clamp Band, Assy. 4 08-7100-03-500 08-7100-03-500 08-7100-03-500 08-7100-05-500
41 Small Carriage Bolt 5/16”-18 x 2” 8 08-6050-03-500 08-6050-03-500 08-6050-03-500 08-6050-05-500
42 Small Square Nut 8 08-6400-03 08-6400-03 08-6400-03 08-6400-05
43 Spacer, Ultra-Flex™ 1 08-3860-08 08-3860-08 08-3860-08 08-3860-08
Muffler (Optional — not shown) 1 08-3510-99 08-3510-99 08-3510-99 08-3510-99
1
Air Valve Assembly includes parts through 08-2390-52 (items 2 through 7). To order pump with oil bottle, add letter D to model #. (Example: T8/AAPD.)
*Refer to corresponding elastomer chart in Section 10.
0502 Specialty Code = PTFE-Coated Hardware
All boldface items are primary wear parts.
