WILDEN PUMP & ENGINEERING, LLC WIL-10230-E-02
SECTION 2
WILDEN PUMP DESIGNATION SYSTEM
NOTE: MOST ELASTOMERIC MATERIALS USE COLORED DOTS FOR IDENTIFICATION.
Viton is a registered trademarks of DuPont Dow Elastomers.
MODEL P2 METAL MATERIAL CODES
SPECIALTY CODES
AIR SYSTEM BASE TYPE
T = TURBO-FLO
™
WETTED PARTS & OUTER PISTON
PK = POLYPROPYLENE / PVDF
PP = POLYPROPYLENE /
POLYPROPYLENE
AIR CHAMBERS
A = ALUMINUM
C = PTFE-COATED ALUMINUM
N = NICKEL-PLATED ALUMINUM
S = STAINLESS STEEL
W = CAST IRON
CENTER BLOCK
A = ALUMINUM
C = PTFE-COATED ALUMINUM
N = NICKEL-PLATED ALUMINUM
P = POLYPROPYLENE
S = STAINLESS STEEL
AIR VALVE
A = ALUMINUM
B = BRASS
C = PTFE PFA COATED
D = BRASS W/OIL BOTTLE
N = NICKEL PLATED ALUMINUM
S = STAINLESS STEEL
DIAPHRAGMS
BNS = BUNA-N (Red Dot)
FSS = SANIFLEX™
[Hytrel
®
(Cream)]
EPS = EPDM (Blue Dot)
NES = NEOPRENE (Green Dot)
PUS = POLYURETHANE (Clear)
TEU = PTFE W/EPDM
BACK-UP (White)
TNU = PTFE W/NEOPRENE
BACK-UP (White)
TSU = PTFE W/SANIFLEX™ BACK-UP
(White)
BNU = BUNA-N, ULTRA-FLEX™ (Red
Dot)
EPU = EPDM, ULTRA-FLEX™ (Blue Dot)
NEU = NEOPRENE, ULTRA-FLEX™
(Green Dot)
VTU = VITON
®
, ULTRA-FLEX™ (White
Dot)
VTS = VITON
®
(White Dot)
WFS = WIL-FLEX™ [Santoprene
®
(Orange Dot)]
VALVE BALL
BN = BUNA-N (Red Dot)
FS = SANIFLEX™
[Hytrel
®
(Cream)]
EP = EPDM (Blue Dot)
NE = NEOPRENE (Green Dot)
PU = POLYURETHANE (Brown)
TF = PTFE (White)
VT = VITON
®
(White Dot)
WF = WIL-FLEX
™
[Santoprene
®
(Orange
Dot)]
VALVE SEAT
K = PVDF
P = POLYPROPYLENE
VALVE SEAT O-RING
BN = BUNA-N
PU = POLYURETHANE
TV = PTFE ENCAP. VITON
®
WF = WIL-FLEX
™
[Santoprene
®
(Orange
Dot)]
0100 Wil-Gard II™ 110V
0102 Wil-Gard II™, sensor wires ONLY
0103 Wil-Gard II™ 220V
0145 Accu-Flo™, 110V AC x-proof coil, Wil-Gard II™ 110V
0150 Accu-Flo™, 24V DC coil
0151 Accu-Flo™, 24V AC / 12V DC coil
0153 Accu-Flo™, 24V AC / 12V DC x-proof coil
0154 Accu-Flo™, 24V DC x-proof coil
0155 Accu-Flo™, 110V AC coil
0156 Accu-Flo™, 110V AC x-proof coil
0157 Accu-Flo™, 24V DC coil, international,
PTB approved
0164 Accu-Flo™, 110V AC coil,
Wil-Gard sensor wires only
0167 Accu-Flo™ 24V AC / 12V DC coil,
Wil-Gard II™ 110V
0168 Accu-Flo™, 110V AC coil, Wil-Gard II™ 110V
0169 Accu-Flo™, 110V AC coil, PFA coated hardware
0170 Accu-Flo™, 110V AC x-proof coil,
PFA coated hardware
0180 Accu-Flo™, 24V AC / 12V DC coil,
PFA coated hardware
0181 Accu-Flo™, 24V AC / 12V DC x-proof coil,
PFA coated hardware
0183 Accu-Flo™, 24V AC / 12V DC x-proof coil,
Wil-Gard II™ 110V
0184 Accu-Flo™, 24V DC coil, PFA coated hardware
0185 Accu-Flo™, 24V DC x-proof coil,
PFA coated hardware
0206 PFA coated hardware,
Wil-Gard II™ sensor wires ONLY
0360 Accu-Flo™, 24V DC coil, DIN flange
0362 Accu-Flo™, 110V AC coil, PFA coated hardware,
Wil-Gard II™ 110V
0363 Accu-Flo™, 110V AC coil, Stallion
®
internals
(balls & seats)
0502 PFA coated hardware
0513 SS outer pistons
0560 Split manifold
0561 Split manifold, PFA coated hardware
0563 Split manifold, discharge ONLY
0564 Split manifold, inlet ONLY
0608 PFA coated hardware, Wil-Gard II™ 220V
0660 Split manifold, Wil-Gard II™ 110V
0661 Split manifold, PFA coated hardware,
Wil-Gard II™ 110V
T or A8X/XXXXX/XXX/XX/XXX/ XXXX
O-RINGS
MODEL VALVE SEAT
VALVE BALLS
DIAPHRAGMS
AIR VALVE
CENTER BLOCK
AIR CHAMBERS
WETTED PARTS & OUTER PISTON
AIR SYSTEM BASE TYPE
SPECIALTY
CODE
(if applicable)
