27
WILDEN PUMP & ENGINEERING, LLCWIL-10230-E-02
A8 PLASTIC ACCU-FLO™ Rubber-Fitted PTFE-Fitted
Item Part Description Qty.
A8/
PKAPA/0150
P/N
A8/
PKSSA/0150
P/N
A8/
KKAPA/0150
P/N
A8/
KKSSA/0150
P/N
A8/PKAPA/
TF/TF/PTS/0150
P/N
A8/PKSSA/
TF/TF/PTS/0150
P/N
A8/KKAPA/
TF/TF/KTV/0150
P/N
A8/KKSSA/
TF/TF/KTV/0150
P/N
1 Solenoid Valve Assembly
1
1 08-2000-99-150 08-2000-99-150 08-2000-99-150 08-2000-99-150 08-2000-99-150 08-2000-99-150 08-2000-99-150 08-2000-99-150
2 Main Valve Body 1
08-2000-01-150 08-2000-01-150 08-2000-01-150 08-2000-01-150 08-2000-01-150 08-2000-01-150 08-2000-01-150 08-2000-01-150
3 Coil 1
00-2110-99-150 00-2110-99-150 00-2110-99-150 00-2110-99-150 00-2110-99-150 00-2110-99-150 00-2110-99-150 00-2110-99-150
4 Terminal Connector 1
00-2130-99 00-2130-99 00-2130-99 00-2130-99 00-2130-99 00-2130-99 00-2130-99 00-2130-99
5 Operator 1
00-2120-99 00-2120-99 00-2120-99 00-2120-99 00-2120-99 00-2120-99 00-2120-99 00-2120-99
6 Air Valve Gasket — Buna-N 1
08-2600-52 08-2600-52 08-2600-52 08-2600-52 08-2600-52 08-2600-52 08-2600-52 08-2600-52
7 Air Valve Screw 4
08-6000-03 08-6000-03 08-6000-03 08-6000-03 08-6000-03 08-6000-03 08-6000-03 08-6000-03
8 Center Block 1
08-3100-20-225 08-3100-03-225 08-3100-20-225 08-3100-03-225 08-3100-20-225 08-3100-03-225 08-3100-20-225 08-3100-03-225
9 Center Block Glyd™ Ring 7
08-3210-55-225 08-3210-55-225 08-3210-55-225 08-3210-55-225 08-3210-55-225 08-3210-55-225 08-3210-55-225 08-3210-55-225
10 Block Gasket — Buna-N 2
08-3520-52 08-3520-52 08-3520-52 08-3520-52 08-3520-52 08-3520-52 08-3520-52 08-3520-52
11 Shaft, Rubber/TPE 1
08-3805-09 08-3805-09 08-3805-09 08-3805-09 N/A N/A N/A N/A
Shaft, Ultra-Flex™/PTFE 1
08-3840-09 08-3840-09 08-3840-09 08-3840-09 08-3840-09 08-3840-09 08-3840-09 08-3840-09
12 Piston, Outer 2
08-4550-21-500 08-4550-21-500 08-4550-21-500 08-4550-21-500 08-4600-21-500 08-4600-21-500 08-4600-21-500 08-4600-21-500
Piston, Outer, Ultra-Flex™ 2
08-4560-21 08-4560-21 08-4560-21 08-4560-21 N/A N/A N/A N/A
13 Piston, Inner 2
08-3700-01 08-3700-03 08-3700-01 08-3700-03 08-3750-01 08-3750-03 08-3750-01 08-3750-03
Piston, Inner, Ultra-Flex™ 2
04-3700-08 04-3700-08 04-3700-08 04-3700-08 N/A N/A N/A N/A
14 Air Chamber, Counter Sunk 2
08-3650-01 08-3650-03 08-3650-01 08-3650-03 08-3650-01 08-3650-03 08-3650-01 08-3650-03
15 Air Chamber Screw - 3/8”-16 x 3-9/16” 3
08-6200-08 08-6200-03 08-6200-08 08-6200-03 08-6200-08 08-6200-03 08-6200-08 08-6200-03
16 Air Chamber Cone Nut 3/8”-16 3
08-6550-08 08-6550-03 08-6550-08 08-6550-03 08-6550-08 08-6550-03 08-6550-08 08-6550-03
17 Liquid Chamber 2
08-5000-20 08-5000-20 08-5000-21 08-5000-21 08-5000-20 08-5000-20 08-5000-21 08-5000-21
18 Discharge Elbow 2
08-5230-20 08-5230-20 08-5230-21 08-5230-21 08-5230-20 08-5230-20 08-5230-21 08-5230-21
19 Inlet Elbow 2
08-5220-20 08-5220-20 08-5220-21 08-5220-21 08-5220-20 08-5220-20 08-5220-21 08-5220-21
20 Manifold T-Section 2
08-5160-20 08-5160-20 08-5160-21 08-5160-21 08-5160-20 08-5160-20 08-5160-21 08-5160-21
21 Ball Guide Bushing 4
08-5350-20-500 08-5350-20-500 08-5350-21-500 08-5350-21-500 08-5350-20-500 08-5350-20-500 08-5350-21-500 08-5350-21-500
22 Valve Seat O-Ring* 4
* * * * 08-1200-59-500 08-1200-59-500 08-1200-60-500 08-1200-60-500
23 Manifold O-Ring* 4
* * * * 08-1300-59-500 08-1300-59-500 08-1300-60-500 08-1300-60-500
24 Diaphragm* 2
* * * * 08-1010-55 08-1010-55 08-1010-55 08-1010-55
25 Diaphragm, Backup 2
N/A N/A N/A N/A 08-1060-51 08-1060-51 08-1060-51 08-1060-51
26 Valve Ball* 4
* * * * 08-1080-55 08-1080-55 08-1080-55 08-1080-55
27 Valve Seat 4
08-1120-20-500 08-1120-20-500 08-1120-21-500 08-1120-21-500 08-1120-20-500 08-1120-20-500 08-1120-21-500 08-1120-21-500
28 Large Clamp Band 2
08-7300-03-500 08-7300-03-500 08-7300-03-500 08-7300-03-500 08-7300-03-500 08-7300-03-500 08-7300-03-500 08-7300-03-500
29 Large Carriage Bolt 3/8”-16 x 2-1/2” 4
08-6070-03-500 08-6070-03-500 08-6070-03-500 08-6070-03-500 08-6070-03-500 08-6070-03-500 08-6070-03-500 08-6070-03-500
30 Large Hex Nut 3/8”-16 4
08-6450-03 08-6450-03 08-6450-03 08-6420-03 08-6450-03 08-6450-03 08-6450-03 08-6450-03
31 Medium Clamp Band 4
08-7200-03-500 08-7200-03-500 08-7200-03-500 08-7200-03-500 08-7200-03-500 08-7200-03-500 08-7200-03-500 08-7200-03-500
32 Medium Carriage Bolt 5/16”-18 x 2-1/4” 8
04-6070-03 04-6070-03 04-6070-03 04-6070-03 04-6070-03 04-6070-03 04-6070-03 04-6070-03
33 Medium Hex Nut 5/16”-18 8
08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03
34 Small Clamp Band 4
08-7100-03-500 08-7100-03-500 08-7100-03-500 08-7100-03-500 08-7100-03-500 08-7100-03-500 08-7100-03-500 08-7100-03-500
35 Small Hex Head Cap Screw 5/16”-18 x 1-3/4” 8
08-6050-03-500 08-6050-03-500 08-6050-03-500 08-6050-03-500 08-6050-03-500 08-6050-03-500 08-6050-03-500 08-6050-03-500
36 Small Square Nut 8
08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03 08-6400-03
Muffler (Optional — not shown) 1
08-3510-99 08-3510-99 08-3510-99 08-3510-99 08-3510-99 08-3510-99 08-3510-99 08-3510-99
37 Spacer, Ultra-Flex™ 1
08-3860-08 08-3860-08 08-3860-08 08-3860-08 08-3860-08 08-3860-08 08-3860-08 08-3860-08
38 Bumper Pad 2
08-6900-23-50 08-6900-23-50 08-6900-23-50 08-6900-23-50 08-3860-08 08-3860-08 08-6900-23-50 08-6900-23-50
1
Solenoid Assembly includes items 2, 3, and 4.
NOTE: Additional solenoid options are available. Please consult Section 10B for electrical reference.
0150 Specialty Code = Solenoid-operated, 24V DC.
* Refer to corresponding elastomer chart in Section 10.
All boldface items are primary wear parts.
