Wilden T8 - Section 10 - Reference; Elastomer Options; Accu-Flo Electrical Information

28
WILDEN PUMP & ENGINEERING, LLC WIL-10230-E-02
SECTION 10A
ELASTOMER OPTIONS
SECTION 10B – ACCU-FLO™
ELECTRICAL REFERENCE
T8 PLASTIC
MATERIAL
TRADITIONAL
DIAPHRAGMS (2)
ULTRA-FLEX™
DIAPHRAGMS (2)
VALVE SEAT
O-RINGS (4)
MANIFOLD
O-RINGS (4) VALVE BALL (4)
Polyurethane 08-1010-50 N/A 08-1200-50-500 08-1300-50-500 08-1080-50
Neoprene 08-1010-51 08-1020-51 N/A N/A 08-1080-51
Buna-N 08-1010-52 08-1020-52 08-1200-52-500 08-1300-52-500 08-1080-52
EPDM 08-1010-54 08-1020-54 N/A N/A 08-1080-54
Viton
®
08-1010-53 08-1020-53 N/A N/A 08-1080-53
Sanifl ex™ 08-1010-56 N/A N/A N/A 08-1080-56
PTFE 08-1010-551 N/A N/A N/A 08-1080-55
Tetra-Flex™ PTFE, Neoprene Backed 08-1010-64 N/A N/A N/A N/A
Tetra-Flex™ PTFE, EPDM Backed 08-1010-81 N/A N/A N/A N/A
Neoprene Backup 08-1060-51 N/A N/A N/A N/A
Wil-Flex™ 08-1010-58 N/A N/A N/A 08-1080-58
PTFE Encap. (Viton®) N/A N/A 08-1200-60-500 08-1300-60-500 N/A
NOTES
PTFE-encapsulated Viton® o-rings, P/N 08-1200-60-500 and P/N 08-1300-60-500, are standard on all PTFE-fi tted pumps.
1
PTFE diaphragm, P/N 08-1010-55, must be used with Neoprene back-up diaphragms, P/N 08-1060-51.
NEMA 4 COIL OPTIONS / UL / CSA (Item 3)
Voltage ±10% Current (A)
AC
AC
DC Power (W) DC Resistivity
Part Number 60 Hz 50 Hz ±10% Inrush Holding (Ω)
00-2110-99-150 24 48 44 4.8 .20 .20 .20 121
00-2110-99-151 12 24 22 4.8 .40 .40 .40 32
00-2110-99-155 60 120 110 4.8 .08 .08 .06 840
NEMA 7 COIL OPTIONS / UL / CSA (Item 3)
Voltage ±10% Current (A)
AC
AC
DC Power (W) DC Resistivity
Part Number 60 Hz 50 Hz ±10% Inrush Holding (Ω)
00-2110-99-153 12 24 22 7 .60 .55 .32 19
00-2110-99-154 24 48 44 7 .30 .30 .18 75
00-2110-99-156 60 120 110 7 .12 .13 .06 475
INTERNATIONAL EXPLOSION PROOF / CENELEC / PTB FILE # EX-91.C.2027
Current (A)
DC Voltage ±10% Power (W) Resistivity
Part Number ±10% Inrush Holding (Ω)
00-2110-99-157 24 3.3 .135 .135 177
OPERATOR OPTIONS (Item 5)
Part Number NEMA Rating
00-2120-99 NEMA 4
00-2121-99 NEMA 7
