Operating instructions
Operation module FB 5210
27
For Installation personnel only
7General Information
7.1Installation notes and preparing for operation
The power supply of the operation module is securred via a bus connection
from the heating circuit module.
The main image is clear after the putting on of the voltage at the boiler and with
that at the heating circuit module in the display of the operation module.
If the normal display falis to appear, presss the recessed reset button to the right
right of the 2nd-level controls. Then set the time and day of week, if necessary.
The reset button starts the controller, without affecting existing settings or the
clock-programme. Use a fine pointed object to operate the reset button.
If no main image appears please check the wiring
.
8Explanation of terms
9Technical data
Operational start The operational start is the programmed start of the
operational time set by the time-switch.
The reservation time is the
time frame during which the
plant is heated on the standard temperature
.
Specialist level These setting levels are reserved for specialists. They
include setting values
for the adaption of the controller
to the heating plant.
Measured value Measured temperature.
Set point Temperature defaulted by the end user or the specialist
onto those the heating controller controls the actual
value.
Power supply:
over data highway (no batteries)
Seonsor cable length cross-section-
al area:
max. 100m
min. 0,75 mm
2
Bus interface: 2-wire-bus, not permutable
Ambient temperature in operation:0°C ... 50°C
Certification: The remote control is
- compliant
