Operating instructions
Operation module FB 5210
9
3.2Adjust displayed room temperature to the measured
It is possible that the temperature displayed on the operation module differs
from the measured (with a room thermometer) temperature
.
1.Keep
actual value of the room temperature
is shown (see "Checking temper-
atures, displaying controller outputs")
starting from page 14).
2.Press the "–" or "+"
side of the key to adjust the displayed value on the operation
module with the measured value on the room temperature thermostat.
Due to pressing the button die
you store your input and go back to the standard
display.
If the measured room temperature (actual value) deviates from the
set value,
through the heating curve on the heating circuit module this can be adjusted
(
see operation module heating circuit module).
