11
Operations
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
ITEM MEASURE
Weight 215 lbs (98kg)
Length 51” (130 cm)
Height 44” (111 cm)
Width 22” (56 cm)
86400940 Operators Manual - CMD20

Other manuals for Windsor Commodore 20

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Windsor Commodore 20 and is the answer not in the manual?

Windsor Commodore 20 Specifications

General IconGeneral
Electrical230V, 8 A, 50 HZ
Power Cable75’ (23 m) (12 gauge)
Electric Propelling Motor(1) –1/4 hp DC (186 watts) with variable speed forward.
Electric Vacuum Motor(1) – 3 stage, 1 hp 99 cfm (2.80 m³/min.)
Drive SystemTransaxle unti variable speed Operating Speed: 0-100ft/min (30m/min)
Waterlift117” (297 cm)
Brush Speed1000 RPM
Solution Capacity20 Gallons (75 ltr)
Recovery Capacity20 Gallons (75 ltr)
Brush(1) 18” (45.8 cm)
Solution Pump100 psi (6.9 BAR), diaphragm style, demand pump
Solution Spray2 quick change jets
Vacuum Shoe22” (56 cm) wide, cast urethane floating and pivoting.
Wheels - Front (2) - Rear (2)4” dia. (10 cm) caster by 2.5” 10” dia (25 cm) wheels by 2”
Weight and Dimensions IconWeight and Dimensions
Dimensions - Weight215 lbs. (98 kg)
Dimensions - Length51” (130 cm)
Dimensions - Height44” (111 cm)
Dimensions - Width22” (56 cm)
