Windsor Commodore 20 User Manual

24
Repuestos sugeridos
PART NO. QTY DESCRIPTION
SEE PAGE IN SPARE PARTS
LIST
86026360 1 PUMP ASM, CMD20 115V Pump
86136800 1 SCREEN, 80 MESH STRAINER DEEP Pump
86313170 1 CAP, STRAINER TALL Pump
86025320 1 IDLER ASM, BRUSH CMD20 Brush
86026130 1 MOTOR ASM, BRUSH CMD20 Brush
86026220 1 PULLEY ASM, BRUSH CMD20 Brush
86026480 1 SOLENOID ASM, CMD20 Manifold and Solenoid
86026040 1 MANIFOLD ASM, CMD20 Manifold and Solenoid
86026870 1 VAC MOTOR ASM, CMD20 Solution Tank
86135320 1 BRUSH SET, 120V VAC, WINDSOR Solution Tank
86025180 1 DOME ASM, CMD20 Recovery Tank
86400940 Operators Manual - CMD20

Windsor Commodore 20 Specifications

General

Electrical	230V, 8 A, 50 HZ
Power Cable	75’ (23 m) (12 gauge)
Electric Propelling Motor	(1) –1/4 hp DC (186 watts) with variable speed forward.
Electric Vacuum Motor	(1) – 3 stage, 1 hp 99 cfm (2.80 m³/min.)
Drive System	Transaxle unti variable speed Operating Speed: 0-100ft/min (30m/min)
Waterlift	117” (297 cm)
Brush Speed	1000 RPM
Solution Capacity	20 Gallons (75 ltr)
Recovery Capacity	20 Gallons (75 ltr)
Brush	(1) 18” (45.8 cm)
Solution Pump	100 psi (6.9 BAR), diaphragm style, demand pump
Solution Spray	2 quick change jets
Vacuum Shoe	22” (56 cm) wide, cast urethane floating and pivoting.
Wheels - Front (2) - Rear (2)	4” dia. (10 cm) caster by 2.5” 10” dia (25 cm) wheels by 2”

Weight and Dimensions

Dimensions - Weight	215 lbs. (98 kg)
Dimensions - Length	51” (130 cm)
Dimensions - Height	44” (111 cm)
Dimensions - Width	22” (56 cm)
