AI Transducer Integration (Temperature Sensor)
DI Transducer Integration (CO Sensor)
Yellow
Red
Black
AI Transducer
4-20mA current
power supply
15...40VDC
24VAC 20%
1 2 3 4
+V
GND
RH
T
DC12v
Adapter
