Chapter 2: Getting Started
EN-17
b. Button functions
* It needs to set up the link device to make the function buttons work.
2.4.3 Contact Sensor(LA5584)
a. Install the battery into the battery compartment.
(Attention: CR2032 battery positive side up)
b. Mount the bracket on the frame side of the door or window, and then put the
reed on the bracket.
Button Press Long press (3 seconds)
FA Full Arm Panic
PA Partial Arm On*
DA Disarm Off*
38mm
28mm
