Chapter 2: Getting Started
EN-19
b. The scan pattern is illustrated in the figure below.
• The effective distance is 8~10m, at 2m height.
• 150-degree at horizontal position.
• 25-degree at vertical position.
c. Pet immune detection could be effective if it meets the following criteria:
• Height: less than 50cm.
• Weight: less than 6kg.
d. To avoid false alarm, do the following:
• Be sure the installation is stable.
• Do not place the device to face any light source directly.
• Never face the sensor to the place that pests can climb up directly.
To save the battery power, there is a 30 seconds lock-out after motion sensor
triggered; which means after the motion sensor triggered, it will stay in sleep
mode for 30 seconds.
• Tamper-proof function is only available for Panel Console, Contact Sensor,
Motion Sensor, and Siren.
• Alarm switch (siren) is highly recommended to be joined/installed at last to avoid
the false alarm caused by unexpected tamper-proof.
80
80
70
70
60
60
50
50
40
40
30
30
20
20
10
10
0
A
B
012345678910111213
(M)
012345678910111213
(M)
AB
1
2
2m
(M)
Distance:10m
Detection area : (Unit=Meter)
