WMF 1500 S+ - Cup Detection

73
User Manual WMF1500S +
Software | System
Cup detection
The cup sensor detects whether there is areceptacle
beneath the spout and determines its height.
Correction of spout position
Setting range: -20mm to +60mm
Minus gSmaller distance from cup
Plus gGreater distance from cup
Steps: 5mm
Standard: 10to 15mm distance
Cup height tolerance
The tolerance for cup height is set here for beverages
with inactive S-M-L.
The height for arecipe is set in the beverage menu.
Thetolerance set here determines how precise this
height must be in order to enable the beverage.
The required tolerance is thus entered here.
Setting range: 0mm to ±30mm
Steps: approx. 7.5mm
Cup detection
DS_04_10_15
