Wolf CGB-75 - Page 51

513062555_201804
Balancedueroute,verticalandconcentric(examples)
1 Gascondensingboiler
2 Gascondensingboiler
connectionsDN110/160
3 Inspectionpiece
3a Inspectionpiece,87°tee
4 PipeclipDN160
5 BalancedueDN110/160
500 mm
1000 mm
2000 mm
6 MountingbracketDN160
for roof outlet
7 Universaltilefor
pitchedroof25-45°
7a "Klöber"adapter20-50°
8 Flatroofcollar
9 Balancedueroutingvertical
(roofoutlet)
foratorpitchedroof
 L=2000mm
10 Bend 45° DN 110/160
11 Bend 87° DN 110/160
12 87°bendforductinstallation
DN 110/160
13 ExternalwallsupportbendF87°
withsmoothendsonbothsideof
theairpipeDN110/160
14 Airinlet,externalwallF
DN 110/160
15 PPwalloutlet,externalwallF
16 Wallplate160
17 Balancedueroutinghorizontal
incl. cowl
18 Connectiontouegaschimney
B33,Length 250 mm with air
apertures
19 Supportbend87°, DN 110
forconnectiontoaueinaduct
20 Supportrail
Notes: Lubricate the pipe ends and gaskets for easi-
er installation.
Check the required inspection piece
(3), (3a) (Part No.: 2651329) with your local
uegasinspectorpriortoinstallation.
TypeC33x:Gascondensingboilerwithcombustionairanduegas
routed vertically via the roof.
Ventilation air aperture for room sealed operation
accordingtoTRGI150cm²or2x75cm².
7
7a
6
8
56
11
3
3
3
5
4
4
4
5
5
5
5
10
10
2
1
2
1
2
1
3a
6
9
6
9
6
9
28.Technicalinformation
