Troubleshooting Guide
5-6
In Manual Test Mode, press a key to activate a fan, motor or other functions. The fan and motor relays will close to
complete a 240 VAC circuit through a specific fan or motor. If the Oven Controller detects the functionality through
switches, an indicator will be illuminated on the corresponding display.
NOTE: Diagnostic Mode will end 5 minutes after last key stroke or when the CLEAR key is pressed.
NOTE: See Figure 5-7 for Icon display location
Figure 5-5. Element Testing Chart
(“On” will be displayed and applicable convection fan icon will be illuminated indicating current flow.)
Fans and Motors
First access Diagnostic Mode. Once in Diagnostic Mode, the technician will need to select option #2 (Manual Test
Mode) and then a key can be pressed to activate a fan or a motor. The fan or motor relays will close to complete a
240 VAC circuit to a specific fan or motor. If the Oven Controller detects the functionality of the Board, an indicator
will be illuminated on the display. Device operation however must be verified physically.
NOTE: Diagnostic Mode will end 5 minutes after last key stroke or when the CLEAR key is pressed.
Figure 5-6. Fans and Motors Testing Chart
Key Pressed Relay(s) Activated Action Display Response
Key 6 Cooling Fan Cooling Fan Cooling Fan Test On
Key 7 Motor Door Lock (MDL) MDL switch in open position MDL is open
Motor Door Lock (MDL) MDL in transition MDL is in process: Up arrow illuminated
Motor Door Lock (MDL) MDL switch in closed position MDL is closed: Up arrow illuminated
Key 8 Left Convection Fan Left Convection Fan Left Convection Fan Test On
Key 9 Right Convection Fan Right Convection Fan Right Convection Fan Test On
Upper/Lower Not applicable Switch to opposite cavity
Oven Light Oven Light Light turns on Lights Test On
Timed Cook Beeper Beeper Beeper Test On
Lock None Returns to initial Service Menu Not applicable
Key Pressed Relay(s) Activated Display Response (Upper and Lower Information Lines)
Bake Inner Bake Element Inner Bake Element On Press Bake to toggle
Broil Broil Element Broil Element Press Broil to toggle
Convection Bake Outer Bake Element Outer Bake Element Press Conv. Bake to toggle
Convection Broil Right Convection Element Right Conv. Element Press Conv. Broil to toggle
Convection Left Convection Element Left Conv. Element Press Conv. to toggle
