PAGE 30
Element Testing Chart:
Key Press Relay(s) Activated Display Response (Upr and Lwr Info Lines)
Bake Inner Bake Element Inner Bake Element On Bake to toggle
Broil Broil Element Broil Element Broil to toggle
Conv Bake Outer Bake Element Outer Bake Element Conv. Bake to toggle
Conv Broil Rt Conv Element Right Conv. Element Conv. Broil to toggle
Conv Lft Conv Element Left Conv. Element Conv. to toggle
Key Press Relay Active Action Display Response
Key 6 Cooling Fan Cooling Fan Cool Fan Test On
Key 7 Motor Door Lock MDS sw open position MDS is open
Motor Door Lock MDS in transition Up arrow illuminated
Motor Door Lock MDS sw closed position Up arrow illuminated
Key 8 Left Conv Fan Left Conv Fan Lft Conv Fan Test On
Key 9 Right Conv Fan Right Conv Fan Rt Conv Fan Test On
Up/Lwr Not applicable Switch cavity
Oven Light Oven Light Light turns on Lights Test On
Timed Cook Beeper
Beeper
Beeper Test On
Lock None Rtrn to initial Svc Menu Not applicable
Component Testing Chart:
E-SERIES Manual Test Mode
Enter into the Manual Test by entering Diagnostics/Showroom Mode (Press and
hold TIMER 3 Seconds) and choosing the Manual Test from the Service Mode
Entry menu (Key Press 2).
NOTE: If a communication failure with the Relay Module exists, Manual Test
entry will be inhibited and an appropriate message displayed in the LILA.
NOTE: Double Oven will default to upper cavity upon entry, press Upper/Lower
key to select cavity being tested.
