PAGE 45
Mode 5 - Checking Heat Sink Thermistor
on Power Board
To enter Mode 5 while engaged in diagnostic mode, touch the “+”
keypad on the left front control. When this is done the result will be:
• The bar lights on the left front control will illuminate 5 LEDs
and
flash at the rate mentioned in Mode1.
• The bar lights on the left rear control will illuminate a number of
LEDs based on the temperature of the heat sink thermistor on the
power board using four Hex Decimal Characters and flash at the
rate described in Mode 1. (See Figure 2).
Mode 6 - Checking the Lid Switch on the Cover
To enter Mode 6 while engaged in diagnostic mode, touch the “+”
keypad on the left front control. When this is done the result will be:
• The bar lights on the left front control will illuminate 6 LEDs
and
flash at the rate mentioned in Mode1.
• The bar lights on the left rear control will illuminate 4 LEDs in hex
decimal form, based on the Lid Switch status (open or closed) and
flash at the rate mentioned in Mode1. (See Figure 3).
NOTE: If the numbers are between 580 to 748, the Lid switch is
open.
NOTE: If the numbers are between 239 to 443, the Lid Switch is
closed.
NOTE: Any other numbers other than 580 to 748 and 239 to 443,
mean error.
