Worcester GB162-100

DISPLAY INFORMATION
6 720 648 726 (2011/07)
71
14.3 BC10 DISPLAY SETTINGS
14.4 BC10 DISPLAY CODES
Display settings
Display
setting
Meaning of display setting Unit Range
Factory
adjusted
setting
[l/9/9| Configured target load (65 kW). % [l/2/0| – [l/9/9| / [l/-/-| 100 % [l/-/-|
[l/9/9| Configured target load (80 kW). % [l/2/5| – [l/9/9| / [l/-/-| 100 % [l/-/-|
[l/9/9| Configured target load (100 kW). % [l/2/0| – [l/9/9| / [l/-/-| 100 % [l/-/-|
[f/\.5| Configured target value of the
pump run-over time.
Note: Do not set a pump
run-over time of less than
[f/\/5| (= 5 minutes).
min. [f/0/0| – [f/6/0| / [f/1/d| 24 h [f/\/5|
[c/\.1| DHW supply operating condition
setting.
Please note: If the setting [c/\/0| is
displayed, the frost protection of
the DHW supply has also been
switched off.
not
appli-
cable
[c/\/0| Off / On [c/\/1|
Table 23 Display settings
Display codes
Display code LED on
UBA 3
Other effects
z
Main
display
code
z
Sub
display
code
z
Key to display code
Reset
requi-
red?
[\/-/\| Operating phase:
Communication test while starting up. This
display code flashes 5 times within
5 seconds while starting up to indicate that
the communication between the UBA 3 and
the BC10 basic controller is being tested. If
a new UBA 3 or a new KIM was fitted, this
code will flash for max. 10 seconds.
Off or
flashing
at 8 Hz
[\/-/\| Fault:
If this code continues to flash on the display,
there is a fault in the communication
between the UBA 3 and the BC10 basic
controller.
Off or
flashing
at 8 Hz
e [-/a/\]
1)
e [2/0/8|
2)
Operating phase:
The boiler is in flue gas test or service mode.
Off or
flashing
at 8 Hz
No heating operation
and no DHW.
e [-/h/\| e [2/0/0|
2)
Operating phase:
The boiler is in heating mode.
Off
Table 24 Display codes
