15.2 SPARE PARTS LIST GB162-65
For a pictorial representation of the part see the respective position number on the exploded view pictures on page 91
and 92.
Description Product No.
1 Door 8718689173
2 Sealing door 73912
3 Door lock 73911
4 Hinge door 73990
5 Wall mounting bracket 73965
6 Bracket left 73962
7 Bracket right 73963
8 Adjusting foot 73949
9 Transport slide (L + R) 73951
10 Drawer modules 73964
11 Screw 4.2 x 8.5 x (10 pc) 73988
12 Condensate collector 73930
13 Seal condensate collector 7746900152
14 Seal 80 mm 73931
15 Upper side condensate
collectors
73934
16 Mounting flue-gas pipe 73907
17 Exhaust pipe 73927
18 Adapter air inlet 73938
19 Seal 80 mm 73931
20 Condensate trap 73933
21 Seal condensate trap 73463
22 Drain pipe 73932
23 Seal bush (white) 73449
24 Condensate drain pipe 73995
25 Fan 73924
26 Seal Fan 73920
27 Seal Fan 7099712
28 Venturi 7746900576
29 Seal Ø 50 mm 73574
30 Gas valve 7746700150
31 Seal 33 x 24 x 3.5 (10 pc) 73368s
32 Gas pipe 73975
33 Flange gas valve 8718600286
34 O-ring (10 pc) 73982
36 Screw M5 x 20 (10 pc) 73572s
37 Screw M5 x 16 (10 pc) 73970
38 Screw M6 x 16 (10 pc) 73971
39 Air inlet pipe 73926
40 Seal (10 pc) 73969
41 Air vent revision set 73916
42 Clip 73973
43 Sensor NTC 78159
44 Clip (3 x 2 pc) 78156s
45 O-ring 9.19 x 2.62 (10 pc) 78175s
46 Pressure sensor 73915
47 O-ring 14 x 1.78 (10 pc) 73679s
48 Return/Supply pipe 73950
49 Connection nipple CH 73080
50 Clip 73974
51 O-ring (10 pc) 73972
52 Ignitor housing (incl. glow
ignitor and ionisation
electrode)
8718600172
60 Heat exchanger 8718600269
61 Cover controler BC10 73698
62 Burner 73917
63 Seal Burner 73918
65 Burner box with clamps 73919
66 Facia 8718689154
67 Controller connection plate 73692
68 On/Off switch 73660
69 Knob BC10 38724
70 Draw connection board 73909
71 Cover control box 73977
72 Cover connection board 230 V 73815
73 Transformer 73697
74 UBA 3 8718600083
75 Fuse 5AF (10 pc) 73904s
76 Connection board 73814
77 Electronic connection red 73776
78 Electronic connection grey 73774
79 Electronic connection green 73773
80 Electronic connection blue 73775
