10.1.8 Wiper with Rinse (Oponal)
The windshield wiper switch on the dash of the 280DC-X allows you to operate the windshield wiper system
on the vessel if this oponal feature was purchased.
This switch is a pushbuon style switch and has three buons located on the face of the switch
as well as three LED lights that show the user what mode and speed it is currently operang at.
Please refer to secon 6.10.15 for a detailed user manual explaining the operaon and funcon
of this switch.
This switch will acvate the rinse system included in the wiper opon. The rinse system is ed
into the freshwater supply on the vessel. In-order for the rinse system to funcon properly the fresh water
pump must be turned on. The fresh water pump switch is a labeled push buon mechanical switch located
on the dash of the 280DC-X.
10.1.9 Marine Head
Your 280DC-X comes equipped with an electric marine head system. The control panel for
the head is located inside the head compartment on the port side, beside the head under the
storage shelf. Power is supplied to this panel through a 25 amp breaker located behind the
helm, inside the storage room on the starboard side of the vessel. Water is supplied to the
system from the freshwater pump; therefore, to operate the toilet the freshwater system must
be pressurized. A solenoid installed near the head inlet prevents water from lling the bowl
prior to each use. The macerator pump, located at the rear of the toilet, removes the waste
from the bowl and pumps it into the 9 gal holding tank.
The holding tank is located under the deck on the port side of the boat under the back-to-back seat. This
tank can be evacuated two dierent ways. First is by using the deck pump-out ng located on the port
side of the deck beside the side windshield. Second is by using the overboard discharge. To discharge
overboard, open the access plate located at the top of the step leading down into the head compartment.
Reach inside and open the seacock located on the back side of the discharge ng. Once that is done the
operator can acvate the switch on the dash labeled “overboard discharge” to turn on the macerator pump
and pump overboard. To view the layout of the marine head water system see the drawing in secon 10.4.5.
!!! WARNING
If the solenoid fails or becomes locked in the open posion, shut o the supply system quickly and
evacuate the bowl.
