38 Freedom SW Owner’s Guide
Operating the Freedom SW with the SCP
ABS Finish One Freedom SW unit has completed the
absorption stage and is waiting for other
Freedom SWs in the system to complete
absorption. This status can occur only when
there is another Freedom SW also charging the
battery.
Float The Freedom SW is float charging the batteries
from qualified AC input from the utility grid or
a generator. The Freedom SW is set for three-
stage charging. AC input is also passed through
to the load while float charging.
Fault The Freedom SW has an active fault. The Fault/
Warning LED on the Xanbus SCP is on.
Table 4 Freedom SW Device Setup Screen Operating States (Modes)
State (Mode) Displayed When...
State (Mode) Displayed When...
Gen Support There is AC input from the generator, and the
Freedom SW is supporting the generator by
supplying additional power to the critical loads.
See “Gen Support” on page 66.
Search Search mode is enabled and the Freedom SW is
standing by, waiting to begin inverting. See
“Changing Configurable Settings From The
Device Setup Menu Screen” on page 42.
Passthru The AC connected to the AC1 or AC2 input is
passing directly through the Freedom SW to the
loads. The batteries are not being charged in
this state.
Equalize Equalization has been turned on and the
Freedom SW is equalizing the batteries after
completing a full charge cycle.
FSW Owners Guide.book Page 38 Tuesday, August 7, 2018 9:03 AM
