97-0019-01-01 51
Configuring the Freedom SW using the SCP
Max Chg Rate Sets the percentage of the maximum DC output
current that is available to the charger. The
maximum DC output current for different
models is:
Freedom SW 2012 —100 ADC
Freedom SW 3012 —150 ADC
Freedom SW 2024 —50 ADC
Freedom SW 3024 —75 ADC
If two Freedom SWs are charging the same
battery bank, set each inverter's Max Chg Rate
to 1/n of the desired charge rate (where n is the
number of inverter/chargers).
Charge Cycle Sets the charging method: 3-Stage (bulk,
absorption, float) or 2StgNoFloat
(bulk, absorption, no float).
ReCharge
Volts
Sets the recharging volts to tell the charger to
initiate charging when the battery drains past
the value setting.
AC In
Breaker
Set the breaker limit of incoming AC.
Table 7 Basic Settings
Low Batt Cut
Out
Low Battery Cut Out (LBCO) controls when
the inverter stops producing AC output due to a
low battery voltage condition. The inverter will
stop producing AC output only after this level
has been reached for the period of time set by
the LBCO Delay. This setting is not
temperature compensated.
Table 7 Basic Settings
FSW Owners Guide.book Page 51 Tuesday, August 7, 2018 9:03 AM
