50 Freedom SW Owner’s Guide
Configuring the Freedom SW using the SCP
Table 6 Setting Defaults and Ranges
Model Freedom SW 2012 / 3012 Freedom SW 2024 / 3024
Item Default Min Max Default Min Max
Batt Type Flooded Flooded, Gel,
AGM, Custom
Flooded Flooded, Gel,
AGM, Custom
Batt Capacity
2000-watt models
250Ah 50Ah 2000Ah 250Ah 50Ah 1000Ah
Batt Capacity
3000-watt models
440Ah 440Ah
Max Chg Rate 100% 10% 100% 100% 10% 100%
Charge Cycle 3Stage 3Stage,
2StgNoFloat
3Stage 3Stage,
2StgNoFloat
ReCharge Volts 12.5V 11.0V 13.5V 25.0V 22.0V 27.0V
AC1 Breaker 30A 5A 30A 30A 5A 30A
Low Batt Cut Out 10.5V 10.0V 12.0V 21.0V 20.0V 24.0V
Table 7 Basic Settings
Item Description
Batt Type Sets the system battery chemistry and type:
Flooded, AGM, Gel, and Custom.
Selecting Custom displays the Custom
Settings item, which allows you to adjust the
settings for each charging stage.
Batt
Capacity
Selects the system battery capacity in
amp hours. Setting the battery capacity to 0
resets the charging current to its default values.
Zero Ah battery capacity implies there is no
absorption exit current criteria and absorption
only exits when the absorption timer (default
3hrs, range 1min-8hr) expires.
FSW Owners Guide.book Page 50 Tuesday, August 7, 2018 9:03 AM
