XENO 4CH - Search Panel

71 | Full HD Digital Video Recorder
No. Button
Description
1
Navigation
Key
8 directional arrows allow the user to move the PTZ camera. The PTZ Camera is
moved when one of these arrows are pressed to the direction desired, and stops the
movement if mouse button is released.
2 Zoom Zoom In and Zoom Out.
3 Focus Adjust the focus of PTZ camera.
4 Virtual PTZ
If Virtual PTZ is activated, able to control PTZ camera such as movement, Zoom and
Focus. PTZ can be controlled by clicking mouse on channel screen directly.
5 PTZ Speed Adjust PTZ camera response speed. Getting Slower as moves to the right.
6 Preset Set PTZ presets on current view.
7 Go to the preset location.
8 Save the preset location.
6.4.8 Search Panel
The Search panel is activated only in Search mode.
When you connect to a site in Search mode, the date is highlighted in Red color in the calendar, if the recorded data exist.
Select a specific date in the calendar and then recording information will be shown in the table.
(Go button) should be pressed to start playback from the selected time.
If DST is enabled, the earlier one-hour overlapped video will be shown first.
