Page #288 background image
11 - 20
Presentation
Sensitivity
Range 0-20 (*1) TRGPMS## 4-11
Presentation
Centering Window
Presentation
Centering On
PDCWIN1 4-12
*Presentation
Centering Off
PDCWIN0 4-13
Left of Presentation
Centering Window
(*40%)
PDCLFT### 4-13
Right of
Presentation
Centering Window
(*60%)
PDCRGT### 4-13
Top of Presentation
Centering Window
(*40%)
PDCTOP### 4-13
Bottom of
Presentation
Centering Window
(*60%)
PDCBOT### 4-13
In-Stand Sensor
Mode
Sensor On TRGSSW1 4-14
Sensor Off TRGSSW0 4-14
CodeGate *CodeGate Off Out-
of-Stand
AOSCGD0. 4-14
CodeGate On Out-
of-Stand
AOSCGD1. 4-14
Streaming
Presentation
Streaming
Presentation Mode -
Normal
PAPSPN 4-15
Streaming
Presentation Mode -
Enhanced
PAPSPE 4-15
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page
