Specifications
8-10 Xerox 4112/4127 EPS
User Guide
Stapling (variable length) Maximum stapled sheets: 100 sheets
Note
When using paper of size larger than A4 or 8.5 Þ 11 in., the
maximum number of sheets that can be stapled is 65.
Note
Staple nails may bend when using certain paper types.
Paper size :
• Maximum: A3, 11 x 17 in.
• Minimum: B5
Staple position :
• 1 location: (front: angled stapling, center: parallel
stapling, back: parallel stapling)*
• 2 locations: (parallel stapling)
Note
* Angled stapling for A3 and A4
Hole Punching Supported paper size:
• Maximum: A3, 11 x 17 in.
• Minimum: B5 (2 holes), A4 (4 holes)
Number of holes: 2, 4, 3 (optional)
Paper type: 52 - 200 gsm
Booklet Creation/Single Fold Maximum number of sheets:
Fold & Staple: 25 sheets
Fold only: 5 sheets
Note
When using Xerox 20 lb./75 gsm paper.
Note
Only 19 sheets can be stapled if adding a cover.
Paper size:
• Maximum: A3, 13 x 18 in.
• Minimum: A4 SEF, 8.5 x 11 in. SEF
Paper type:
Fold & Staple: 60 - 90 gsm
Fold only: 60 - 105 gsm
Paper Weight/Booklet Capacity:
64 - 80 gsm, Uncoated: 25 sheets
81 - 90gsm, Uncoated: 20 sheets
91 - 105 gsm, Uncoated: 10 sheets
106 - 128 gsm, Uncoated: 10 sheets, Coated: 10 sheets
129 - 150 gsm, Uncoated: 10 sheets, Coated: 10 sheets
151 - 176 gsm, Uncoated: 10 sheets, Coated: 10 sheets
177 - 220 gsm, Uncoated: 5 sheets, Coated: 5 sheets
Folding Note: Non-stapled fold sets are limited to 5 sheets of paper
Refer to the optional Folder table on page 8-12 for folder
specifications.
Item Specification
