Addendum
9-8 Xerox 4112/4127 EPS
User Guide
10. From the tray properties screen, select the desired option (Paper Size, Paper Type/Paper
Weight, etc.).
11. Make the appropriate changes to that option (such as Paper Size).
12. Select the Save button to continue.
13. Select the Save button again to continue.
14. Select the Confirm button to save the information and close the Paper Tray settings screen.
Skew adjustment levers
The skew adjustment levers are found in all paper trays. These levers are used to improve paper
feed accuracy and to reduce paper skew problems.
Note
• These levers should remain in their default position. The position of these levers should be
changed only when there is a skew problem when running a specific print job and/or
specific media type.
• Changing the skew adjustment levers from their default position may cause more skew
problems when running certain media types, such as coated, label, transparency, and film.
Use the following procedure to set the skew adjustment levers.
1. Pull out the tray slowly until it stops.
2. Slide the Rear Skew Adjustment Lever to the right (as shown in the above picture).
3. Gently push in the tray until it comes to a stop.
Item number Description
1 Rear Skew Adjustment Lever
2 Right-side skew Adjustment Lever
