118 6 Troubleshooting
Paper Jams in the Fuser Unit
1. Pull the front cover release levers ("A") on
both sides of the printer towards you and
open the front cover.
2. Open the top cover.
3. As necessary, hold the lever on the right
side of the fuser cover and open the fuser
cover.
Important
• The fuser is hot. Do not touch areas with labels
indicating high temperature and those surrounding the
labels. Otherwise, you can get burnt.
4. While holding the cover open, use your
other hand to clear the jammed paper.
5. Close the top cover and then the front
cover.
Important
• When closing the front cover, be careful not to get your
fingers caught between (the left, right, top, or bottom
edge of) the cover and the printer.
