Xerox VersaLink B7130 User Manual

Installing the Xerox
®
Printer Manager
Before you begin:
Ensure that you have root or superuser privileges to install Xerox
®
Printer Manager.
To install the Xerox
®
Printer Manager:
1. Download the appropriate package for your operating system. To locate print drivers for your printer, go to
www.xerox.com/drivers.
2. On the print driver website, navigate to your printer model.
3. For your printer model, click DDrriivveerrss && DDoowwnnllooaaddss.
4. From the Operating System menu, select your operating system.
5. To identify the print driver for your printer model, review the list of available print drivers.
Note: For additional information on each driver, click DDeessccrriippttiioonn.
6. To select the print driver for your printer model and operating system, click its name.
7. To begin the download, read the End User License Agreement, then click aacccceepptt.
The file automatically downloads to the default location for your computer file downloads.
8. To install the Xerox
®
Print Driver package:
• Open the package with your OS package manager.
• To install using a command-line utility, change to the directory where you downloaded the file. To run the
installer, type the appropriate command-line utility for your operating system. For example:
• RReedd HHaatt: rpm -U <filename>.rpm
• DDeebbiiaann--bbaasseedd LLiinnuuxx: dpkg -i <filename>.deb
• AAIIXX: rpm -U <filename>.rpm
• HHPPUUXX: <filename>.depot.gz
• SSoollaarriiss: pkgadd -d <filename>.pkg
Note: Most installations create a Xerox directory in /opt/Xerox/prtsys. For additional information about
utilities included in the OS package manager, refer to the manual included with the package. For example,
man xeroxprtmgr.
Launching Xerox® Printer Manager
To launch Xerox
®
Printer Manager, do one of the following tasks.
• For UNIX, log in as root. From a terminal window, type xxoossddpprrttmmggrr, then press EEnntteerr or RReettuurrnn.
• For Linux, type ssuuddoo xxeerrooxxpprrttmmggrr, then press EEnntteerr or RReettuurrnn.
Printing with xeroxprint
Xerox has its own print command. You can use the following command:
xxeerrooxxpprriinntt --dd<<SSoommee__QQuueeuuee>> --oo[[OOppttiioonnss]] <<SSoommeeffiillee>>
138
Xerox
®
VersaLink
®
B71XX Series Multifunction Printer User Guide
Printing

Xerox VersaLink B7130 Specifications

General

N-up printing	16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.2 s
Print speed (black, normal quality, A3)	17 ppm
Duplex print speed (ISO/IEC 24734, A3) black	11 ppm
Print speed (black, normal quality, A4/US Letter)	30 ppm
Optional connectivity	Wireless LAN
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	@PrintByXerox, Apple AirPrint, Mopria Print Service
Processor cores	2
Internal storage capacity	320 GB
Sound power level (standby)	4.1 dB
Sound power level (printing)	6.8 dB
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	4.3 s
Copy speed (black, normal quality, A4)	30 cpm
Display	LCD
Control type	Touch
Product color	Blue, White
Display diagonal	7 \
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	480 W
Power consumption (sleep)	0.4 W
Power consumption (standby)	94 W
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supported	HP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Scan to	E-mail, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 431.8 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPG, TIFF
Document formats supported	PDF
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Faxing	-
PCL fonts	83
Printer fonts	PCL, PostScript
Printing colors	Black
Duplex functions	Copy, Print, Scan
Maximum duty cycle	129000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Page description languages	HP-GL, JPEG, PCL 5, PCL 6, TIFF, XPS
Total input capacity	620 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	520 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	130 sheets
Custom media width	139.7 - 297 mm
Custom media length	182 - 431.8 mm
Duplex media weight	60 - 169 g/m²
Paper tray media types	Bond paper, Card stock, Glossy paper, Heavy paper, Heavy printing media, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5
Multi-purpose tray media types	Bond paper, Envelopes, Glossy paper, Heavyweight paper, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 216 g/m²
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Current rating	12 A
Browser supported	Microsoft, Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages support	Multi
Supported network protocols	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour/AirPrint FTP

Weight and Dimensions

Depth	670.8 mm
Width	615.7 mm
Height	766.5 mm
