d. Place the removed waste cartridge on a level surface, with the openings facing up.
CCaauuttiioonn:: To avoid toner spills or malfunction, do not lay the waste cartridge on its side.
3. Remove the printhead LED lens-cleaning rod from inside the front door.
4. Slowly push the cleaning rod into the printer until it stops, then pull it out. Repeat this action two more times.
200 Xerox
®
VersaLink
®
C71XX Series Color Multifunction Printer User Guide
Maintenance
