Xerox WorkCentre 5019 - Activating the Communication Port

Xerox
®
WorkCentre
®
5019/5021
Network Addendum
13
Activating the communication port
Use CentreWare Internet Services to activate the communication port you want to use.
You can activate the following ports:
For information on how to make settings from CentreWare Internet Services, refer to Setting items on
CentreWare Internet Services on page 17.
To activate a communication port:
1. Start CentreWare Internet Services.
2. Click the Properties tab.
3. Select Connectivity from the menu on the left.
Port Description
SNMP Activate this port when using the SNMP protocol (used for
operations such as loading the machine's information to the print
driver).
LPD Activate this port when printing using LPD.
Port9100 Activate this port when printing using Port9100.
