xFusion Digital Technologies FusionServer 1288H V6

FusionServer 1288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
15
5 Hardware Description
5.1 Front Panel
5.2 Rear Panel
5.3 Processors
5.4 Memory
5.5 Storage
5.6 Network
5.7 I/O Expansion
5.8 PSUs
5.9 Fan Modules
5.10 Boards
5.1 Front Panel
5.1.1 Appearance
⚫
4 x 3.5" drive configuration
Figure 5-1 Front view
1
Drive
2
Slide-out label plate (with an
SN label)
