CPU
Channel
Memory Slot
A
DIMM101(I)
B (primary)
DIMM110(B)
B
DIMM111(J)
C (primary)
DIMM120(C)
C
DIMM121(K)
D (primary)
DIMM130(D)
D
DIMM131(L)
E (primary)
DIMM140(E)
E
DIMM141(M)
F (primary)
DIMM150(F)
F
DIMM151(N)
G (primary)
DIMM160(G)
G
DIMM161(O)
H (primary)
DIMM170(H)
H
DIMM171(P)
5.4.2.3 Memory Compatibility
Observe the following rules when configuring PMem modules:
⚫
The PMem modules must be used with the DDR4 memory modules. For details, see
FusionServer PMem 200 User Guide.
⚫
Contact your local sales representative or see "Search Parts" in the Compatibility Checker
to determine the components to be used.
⚫
The memory must be used with the third-generation Intel
®
Xeon
®
Scalable Ice Lake
processors. The maximum memory capacity supported by all processor models is the
same.
⚫
The PMem module can work only in App Direct Mode (AD) and Memory Mode (MM).
The total supported memory capacity is calculated as follows:
− PMem module in AD mode
Total memory capacity = Total capacity of all PMem modules+ Total capacity of all
DDR4 memory modules
− PMem module in MM mode
