FusionServer 1288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
43
Configuration
Front Drive
Rear Drive
Drive
Management
Mode
support only
NVMe
drives.
10 x 2.5" drive
NVMe configuration
3
⚫
Front drive: 10 x
2.5"
− Slots 0 to 3
support
SAS/SATA/N
VMe drives.
− Slots 4 to 9
support only
NVMe
drives.
⚫
I/O module 1: 2
x 2.5"
− Slots 12 and
13 support
only
SAS/SATA
drives.
⚫
SAS/SATA
drive: 1 x PCIe
RAID controller
card
⚫
NVMe drive:
CPU
Note: Contact your local sales representative or see "Search Parts" in the Compatibility
Checker to determine the components to be used.
5.5.2 Drive Numbering
The drive numbers identified by the RAID controller card vary depending on the cabling of
the RAID controller card. The drive numbers identified by the RAID controller card in this
section are provided based on the default cabling described in "Internal Cabling" in
FusionServer 1288H V6 Server Maintenance and Service Guide.
⚫
4 x 3.5" drive pass-through configuration
Corresponds to 4 x 3.5" drive pass-through configuration 1 in 5.5.1 Drive
Configurations .
Figure 5-22 Slot Numbers
Table 5-10 Slot numbers
Drive No.
Drive Number Identified by the iBMC
0
0
1
1
2
2
