5.4.2.6 Memory Protection Technologies
The following memory protection technologies are supported:
⚫
PMem module Error Detection and Correction
⚫
PMem module Device Failure Recovery (SDDC)
⚫
PMem module Package Sparing (DDDC)
⚫
PMem module Patrol Scrubbing
⚫
PMem module Address Error Detection
⚫
PMem module Data Poisoning (Corrupt Data Containment)
⚫
PMem module Viral
⚫
PMem module Address Range Scrub (ARS)
⚫
PMem module Error Injection
⚫
DDR-T Command and Address Parity Check and Retry
⚫
DDR-T Read Write Data ECC Check and Retry
⚫
PMem module Faulty DIMM Isolation
⚫
PMem module Error Reporting
5.5 Storage
5.5.1 Drive Configurations
Table 5-9 Drive configuration
Configuration
Front Drive
Rear Drive
Drive
Management
Mode
4 x 3.5" drive
pass-through
configuration 1
⚫
Front drive: 4 x
3.5
− Slots 0 to 3
support only
SATA drives.
-
⚫
PCH
4 x 3.5" drive
pass-through
configuration 2
⚫
Front drive: 4 x
3.5
− Slots 0 to 3
support only
SAS/SATA
drives.
⚫
I/O module 1: 2
x 2.5"
− Slots 12 and
13 support
only
SAS/SATA
drives.
⚫
1 x screw-in
RAID controller
card
4 x 3.5" drive
pass-through
configuration 3
⚫
Front drive: 4 x
3.5
− Slots 0 to 3
support only
SAS/SATA
drives.
-
⚫
1 x PCIe RAID
controller card
