FusionServer 1288H V6 Server
Technical White Paper
of ISO 14664-1 Class 8.
⚫
There is no explosive, conductive, magnetic, or corrosive
dust in the equipment room.
NOTE
It is recommended that the particulate pollutants in the equipment room
be monitored by a professional organization.
The declared A-weighted sound power levels (LWAd) and
declared average bystander position A-weighted sound
pressure levels (LpAm) listed are measured at 23°C (73.4°F) in
accordance with ISO 7779 (ECMA 74) and declared in
accordance with ISO 9296 (ECMA 109).
⚫
Idle:
− LWAd: 6.2 Bels
− LpAm: 45.3 dBA
⚫
Operating:
− LWAd: 6.97 Bels
− LpAm: 52.6 dBA
NOTE
Actual sound levels generated during server operation vary depending
on server configuration, load, and ambient temperature.
SSDs and HDDs (including NL-SAS, SAS, and SATA) cannot be preserved for a long time in the
power-off state. Data may be lost or faults may occur if the preservation duration exceeds the specified
maximum duration. When drives are preserved under the storage temperature and humidity specified in
the preceding table, the following preservation time is recommended:
⚫
Maximum preservation duration of SSDs:
⚫
12 months in power-off state without data stored
⚫
3 months in power-off state with data stored
⚫
Maximum preservation duration of HDDs:
⚫
6 months in unpacked/packed and powered-off state
⚫
The maximum preservation duration is determined according to the preservation specifications
provided by drive vendors. For details, see the manuals provided by drive vendors.
6.3 Physical Specifications
Table 6-3 Physical specifications
⚫
3.5" drive chassis: 43.5 mm x 447 mm x 790 mm (1.71 in.
x 17.60 in. x 31.10 in.)
⚫
2.5" drive chassis: 43.5 mm x 447 mm x 790 mm (1.71 in.
x 17.60 in. x 31.10 in.)
