xFusion Digital Technologies FusionServer 1288H V6 - Page 42

FusionServer 1288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
42
Configuration
Front Drive
Rear Drive
Drive
Management
Mode
10 x 2.5" drive
pass-through
configuration 4
⚫
Front drive: 10 x
2.5"
− Slots 0 to 5
support only
SAS/SATA
drives.
− Slots 6 and 7
support
SAS/SATA/N
VMe drives.
− Slots 8 and 9
support only
NVMe
drives.
-
⚫
SAS/SATA
drive: 1 x
screw-in RAID
controller card
⚫
NVMe drive:
CPU
10 x 2.5" drive
pass-through
configuration 5
⚫
Front drive: 10 x
2.5"
− Slots 0 to 5
support only
SAS/SATA
drives.
− Slots 6 and 7
support
SAS/SATA/N
VMe drives.
− Slots 8 and 9
support only
NVMe
drives.
-
⚫
SAS/SATA
drive: 1 x PCIe
RAID controller
card
⚫
NVMe drive:
CPU
10 x 2.5" drive
NVMe configuration
1
⚫
Front drive: 10 x
2.5"
− Slots 0 to 3
support only
SATA/NVMe
drives.
− Slots 4 to 9
support only
NVMe
drives.
-
⚫
SATA drive:
PCH
⚫
NVMe drive:
CPU
10 x 2.5" drive
NVMe configuration
2
⚫
Front drive: 10 x
2.5"
− Slots 0 to 3
support
SAS/SATA/N
VMe drives.
− Slots 4 to 9
⚫
I/O module 1: 2
x 2.5"
− Slots 12 and
13 support
only
SAS/SATA
drives.
⚫
SAS/SATA
drive: 1 x
screw-in RAID
controller card
⚫
NVMe drive:
CPU
